Fiber Coupled InGaAs PIN Photodiodes

Product Description:

The following Series InGaAs PIN photodiodes are designed for optical network monitoring applications and assembled into a hermetically sealed package with an antireflective-coated lens. The fiber is actively aligned to deliver a high responsivity, and the fiber is reinforced with a rubber boot, which relieves fiber bending stresses. These photodiodes exhibit low dark current, low return loss, low noise and high bandwidth, and cover a spectral response range of 1um to 1.65um. ESD protection is required.

Part Number
Package
Cut -off Frequency (GHz)
Active Area (Φ:um)
λ Range (um)
Max ID  (nA)
Responsivity (A/W)
DPIN-231
Fiber Coupled
2.5
55
1.0~1.65
0.5
0.9



Fiber coupled InGaAs PIN photodiodes, SMF-28 fiber, 2.5GHz cut-off frequency, FC/APC connector, in stock, DPIN-23133 ($36.0):





The photodiode has superior noise and photoelectric performance. Contact us for quantity pricing. For more detailed specifications...



Fiber coupled InGaAs PIN photodiodes in stock, HI1060 fiber, 2.5GHz cut-off frequency, FC/APC connector, DPIN-28133 ($72.0):





The photodiode has superior noise and photoelectric performance. Contact us for quantity pricing. For more detailed specifications...



Corning PM1550 Fiber coupled InGaAs PIN photodiodes, 2.5GHz cut-off frequency, FC/APC connector, in stock, DPIN-26133 ($68.0):





The photodiode has superior noise and photoelectric performance. Contact us for quantity pricing. For more detailed specifications...



Fiber coupled InGaAs PIN photodiodes in stock, SMF-28 fiber, 2.5GHz cut-off frequency, 900um loose tube protection, NO connector, DPIN-23113 ($32.0):





The photodiode has superior noise and photoelectric performance. Contact us for quantity pricing. For more detailed specifications...



Fiber coupled InGaAs PIN photodiodes in stock, SMF-28 fiber, 2.5GHz cut-off frequency, 900um loose tube protection and mount flange, NO connector, DPIN-27113 ($38.0):





The photodiode has superior noise and photoelectric performance. Contact us for quantity pricing. For more detailed specifications...



Fiber coupled InGaAs PIN photodiodes in stock, SMF-28 fiber, 2.5GHz cut-off frequency, bare fiber, no connector, DPIN-23513 ($32.0):





The photodiode has superior noise and photoelectric performance. Contact us for quantity pricing. For more detailed specifications...



Fiber coupled InGaAs PIN photodiodes, SMF-28 fiber, 2.5GHz cut-off frequency, LC/APC connector in stock, DPIN-23153 ($38.0):





The photodiode has superior noise and photoelectric performance. Contact us for quantity pricing. For more detailed specifications...



Fiber coupled InGaAs PIN photodiodes, SMF-28 fiber, 2.5GHz cut-off frequency, LC/PC connector in stock, DPIN-23143 ($38.0):





The photodiode has superior noise and photoelectric performance. Contact us for quantity pricing. For more detailed specifications...
